Automatic Navigation System AG500 GNSS

The SunNav AG500 GPS GNSS Automatic Navigation System, equipped with automatic turning capability, delivers top-level autopilot performance even in vehicles that are not factory-prepared for autonomous driving. Ideal for tractors, sprayers, sweepers, and combine harvesters.


Why choose the AG500?


  1. Provides RTK accuracy, reliable everywhere and at all times.
  2. Offers fully localized Greek menus for easy operation.
  3. Supports remote configuration of all implements.
  4. Includes ISOBUS functionality for greater flexibility and connectivity.
  5. Comes with free remote technical support.
  6. Free installation across mainland Greece (with a small additional charge in the Peloponnese).


Features:

The AG500 GNSS stands out for its advanced features, offering easy and quick installation with a very simple calibration process, without requiring modifications to the vehicle’s hydraulic system. Its portability allows use across multiple vehicles, maintaining operational accuracy up to 3 cm on the line. Furthermore, it supports Cloud data storage, while AB line files can be easily shared between different vehicles, ensuring flexibility and efficiency in task management.


EMS4 Motor Wheel



The EMS4 is a high-torque, direct-drive electric steering wheel designed for easy and fast installation. Thanks to its advanced technology, it provides accuracy of up to 2.5 cm RTK, ensuring maximum performance and reliability in every application.



T101 Console

Operating System: Android 9.0 /6.0
LCD: 10.1’’ Capacitive Touch Screen
Wi-Fi: 2.4GHz IEEE 802.11 b/g/n
Bluetooth: V4.0
Serial Port: RS232 x2, RS485 x1
CAN Port: CANx2 (J1939, CANOpen, ISO15765)
Dustproof & Waterproof: IP-65
Dimension: 281mmx181mmx42mm
Weight: 1.5kg





GNSS Antenna

Built-in GNSS board, IMU sensor,
Radio, Antenna
Physical Dimension:179×179×69mm
Weight: 1.1Kg
Protection Level: IP67
Supply Voltage: DC 9~36V
Signal: GPSL1/L2,BDS B1/B2,GLONASS L1/L2,
Galieo E1/E5a/E5b,QZSS L1/L2/L5
Data Format: NMEA 0183, Unicre




The AG500 GNSS is the ideal solution for those seeking reliability, precision, and professional results in agriculture and other demanding applications !
